BS-119
BESIN
Product Description
Honeycomb Ceramic Substrate:
Material: Cordierite (2MgO·2Al₂O₃·5SiO₂)
Cell Density: 200 cpsi (cells per square inch)
Wall Thickness: 0.2mm±0.02mm
Size Options:
| Model | Tolerance | Applicable Flow Rate (m³/h) |
|---|---|---|
| 100×100×50 | ±1mm | 500-800 |
| 150×150×50 | ±2mm | 1,200-1,800 |
| Custom Sizes | ±0.5% | Tailored to requirements |
Designed for industrial VOC abatement in:
Paint spraying/drying
Chemical manufacturing
Food processing
Automotive production
Printing/coating operations
Test Conditions:
Catalyst Size: 100×100×50mm
Space Velocity: 15,000 h⁻¹
Preheat Temperature: Light-off temperature +50℃
| Pollutant | Concentration | Light-off Temp. | Target Temp. |
|---|---|---|---|
| Benzene | 4g/m³ | 240℃ | 290℃ |
| Toluene | 4g/m³ | 220℃ | 270℃ |
| Ethyl Acetate | 5g/m³ | 300℃ | 350℃ |
| Acetone | 5g/m³ | 280℃ | 330℃ |
| n-Butanol | 4g/m³ | 180℃ | 230℃ |
