Shapeful Avtivated Carbon Honeycomb Cubes

Name: Shapeful Avtivated Carbon Honeycomb Cubes
Brand: BESIN
SKU: 563052127
Rating: 5.0 (64 reviews)

Avtivated Carbon Honeycomb Cubes are manufactured from high-quality coal-based activated carbon, which is molded into a honeycomb structure and then activated through high-temperature firing. The product is available in two types: standard honeycomb activated carbon and waterproof honeycomb activated carbon.

The adsorption process involves exposing waste gas to the porous structure of activated carbon, which has a large surface area, effectively capturing pollutants and purifying the gas.

Base Material Powder:	Coal to carbon, wooden carbon, coconut shell/fruit shell carbon
Cell Shape:	Square, triangle, hexagon
Developed Area:	513m2/g
Tolerance Range:	≤±1mm
Regular Size:	100×100 50×50
Thickness:	2-150mm
Strength Requirements:	500N-1500N
Availability:

Quantity:



Inquire Add to Basket

Model:
BS-121
Brand:
BESIN

Product Description

Product Description

Characteristic

High temperature resistance
Well-developed pores
Abundant bubbles
Strong water absorption
Filtering metal residues and odors
Reusable, formaldehyde removal
Ozone removal
Hydrogen sulfide removal
VOC removal, lightweight

Other Specification

Cell Type	Micropores (below 2nm), mesopores/mesopores (2-20nm), macropores 20-50nm, and macropores (>50nm)
Customized Services	Mold making (irregular)
Industrial Application Scenarios	Adsorption box, fan, environmental protection equipment
Craftsmanship	Heating extrusion - drying - kiln firing - post-treatment - polishing
Free Samples	20-50 pieces (with mold)
Package	Carton+wooden box+pearl cotton (<15kg/box), with packaging requirements for separate pricing
Iodine Value	500-1000, customizable
Maximum Size	105×105
Minimum Size	20×20

Application

Activated carbon can remove bad or harmful gas components from the airflow. When air flows through, molecules will gather on the relatively large inner surface of honeycomb-shaped activated carbon, and those chemical molecules that affect odors will also be adsorbed, thereby achieving the effect of deodorization. Pollutants such as carbon dioxide, nitrogen oxides, carbon disulfide, carbon tetrachloride (CTC), hydrogen sulfide, chlorine, benzene, xylene, acetone, ethanol, ether, methanol, acetic acid, styrene, light gas, gasoline, kerosene, and odors can be removed by honeycomb activated carbon. Waterproof honeycomb activated carbon can be used for adsorption purification, separation and recovery, catalyst carrier and environmental industry, and is particularly suitable for purifying large flow and low concentration organic waste gas.
