Ozone Removal Filter

Name: Ozone Removal Filter
Brand: BESIN
SKU: 595353227
Rating: 5.0 (27 reviews)

This advanced filtration system utilizes a macroporous aluminum honeycomb substrate impregnated with a high-performance catalytic composite and activated carbon. The synergistic action of these components effectively decomposes malodorous compounds such as ammonia (NH₃) and hydrogen sulfide (H₂S) through catalytic oxidation and adsorption. Designed for superior air purification, this filter is widely implemented in applications including HVAC systems, air purifiers, industrial deodorization units, and specialized odor control equipment.

Specification:	300*600 or can be customized
Material:	Aluminum
Cell Length:	0.8,1,1.5,1.83,3,4,5 or can be customized
Cell Size:	1.04.1,73,2.60,3.46,5.20 or can be customized
Mesh Number:	1550,992,689,110,62,39 or can be customized
Specific Surface Area:	750,1000,1200，1500,1700 or can be customized
Commen Thickness:	10mm,20mm or can be customized
Availability:

Quantity:



Inquire Add to Basket

Model:
BS-12
Brand:
BESIN

Product Description

Product Description

Specification

Regular Size	200×400×10mm or can be customized
Maximum Size	600*800mm
Common Thickness	10mm
Can Produce Thickness	7/10/12/15/20mm
Surface Treatment	Black
Remarks (maximum temperature, wind resistance, etc.)	Maximum operating temperature: 180 ℃ Wind resistance: 5 Pa

Feature

Large specific surface area, high decomposition efficiency
Free sampling and customized production
Rules for pore formation, low wind resistance

Work Principle

In ventilation systems containing ozone, whenever ozone O3 comes into contact with the surface of the catalyst loaded filter, a rapid decomposition reaction occurs at room temperature. Ozone O3 is instantly decomposed into oxygen O2, and the entire conversion process does not require additional auxiliary energy.

Step1： O3+ Mn → MnO + O2

Step2： MnO + O3→ Mn + 2O2
